Final Products | Yield | Application |
Fuel Oil | 35-40% | 1. Heating material : sell to cement factory, glass factory, ceramic factory, electric power factory, steel making factory ,boiler factory, etc. 2. Used for heavy oil generator for electricity generation. 3. Deep process it into diesel oil by oil distillation machine, then can be used in cars , trucks, tractors, etc. |
Carbon Black | 30-35% | 1. Make it into pellet or briquette as heating material. 2. Make it into N220, N330, N550 or N660 which is widely used in tire making industry. 3. Make it into plastic grains then sold to plastic industry. |
Steel Wire | 10-15% | 1. Sell it to iron and steel factory directly. 2. Sell it to steel distributors. |
Flammable Gas | 8-10% | 1.Recycled into furnace to heat reactor instead of coal/wood/oil/natural gas. 2.Store it then supply the pyrolysis equipment heating ,it’s recycling. |
No. | Items | Contents |
1 | Input-Raw Materials | Waste tire/rubber/plastic/Medical waste/municipal solid waste/waste organic glass |
2 | Final products | Fuel oil, carbon black, steel wire,flammable gas. |
3 | P/N. | LES-2600*6600 |
4 | Capacity/24h | 10Ton/Batch |
5 | Oil production(T)/24h | 4 |
6 | Power(KW) | 5.5 |
7 | Cooling water(T/h) | 6 |
8 | Rotate speed(r/min) | 0.4 |
9 | Heating type | Direct heat |
10 | Cooling type | Water-cooled |
11 | Noise(dB) | <=85 |
12 | Operating | Intermittent |
13 | Driving mode | External gear |
14 | Reactor material | Q345R |
15 | Structure | Horizontal rotation |
16 | Host weight(T) | 26 |
17 | Reactor size(mm) | Ø2600*6600 |
18 | Combustion value | 35-50m3 |
19 | Certification | CE ISO SGS BV |
20 | Land request | 300-400㎡ |
21 | EU emission standard | 100% non-pollution |
